状态化交互 — 2048 小游戏

投票卡是”几乎无状态”的小程序；游戏是”重状态”的——每次操作都改变 4×4 棋盘、 分数、历史栈。这一页用 2048 作为完整案例，带你实现一个真正能玩的聊天内 小游戏。

游戏规则简介

经典 2048：4×4 棋盘 + 按方向键合并相同数字方块；每步随机生成一个 2 或 4； 合并后的数字累加到分数；目标拼出 2048（不强制，可继续玩）。 任何方向都不能再合并 = Game Over。

Agent 端状态机

type Game = {
  board: number[][];     // 4×4，0 表示空
  score: number;
  bestScore: number;
  movesCount: number;
  gameOver: boolean;
  won: boolean;          // 拼出 2048 时
  history: number[][][]; // 每步前的快照（用于撤销）
};


function newGame(): Game {
  const board = Array.from({ length: 4 }, () => Array(4).fill(0));
  spawnTile(board);
  spawnTile(board);
  return { board, score: 0, bestScore: 0, movesCount: 0, gameOver: false, won: false, history: [] };
}


function spawnTile(board: number[][]): boolean {
  const empties: [number, number][] = [];
  for (let r = 0; r < 4; r++) for (let c = 0; c < 4; c++) if (board[r][c] === 0) empties.push([r, c]);
  if (empties.length === 0) return false;
  const [r, c] = empties[Math.floor(Math.random() * empties.length)];
  board[r][c] = Math.random() < 0.9 ? 2 : 4;
  return true;
}


function move(g: Game, dir: "up" | "down" | "left" | "right"): boolean {
  const before = g.board.map((row) => [...row]);
  let moved = false;
  let scoreGain = 0;


  const rotate = (b: number[][], times: number) => {
    let r = b;
    for (let i = 0; i < times; i++) r = r[0].map((_, idx) => r.map((row) => row[idx]).reverse());
    return r;
  };
  const compactRow = (row: number[]): { row: number[]; gain: number } => {
    const arr = row.filter((x) => x !== 0);
    let gain = 0;
    for (let i = 0; i < arr.length - 1; i++) {
      if (arr[i] === arr[i + 1]) {
        arr[i] *= 2;
        gain += arr[i];
        arr.splice(i + 1, 1);
      }
    }
    while (arr.length < 4) arr.push(0);
    return { row: arr, gain };
  };


  const times = { left: 0, up: 1, right: 2, down: 3 }[dir];
  let b = rotate(g.board, times);
  for (let r = 0; r < 4; r++) {
    const { row, gain } = compactRow(b[r]);
    if (row.some((v, i) => v !== b[r][i])) moved = true;
    b[r] = row;
    scoreGain += gain;
  }
  b = rotate(b, (4 - times) % 4);


  if (!moved) return false;


  g.history.push(before);
  if (g.history.length > 5) g.history.shift();
  g.board = b;
  g.score += scoreGain;
  g.bestScore = Math.max(g.bestScore, g.score);
  g.movesCount += 1;
  if (b.some((r) => r.some((v) => v === 2048))) g.won = true;
  spawnTile(g.board);
  if (!canMove(g.board)) g.gameOver = true;
  return true;
}


function canMove(b: number[][]): boolean {
  for (let r = 0; r < 4; r++) for (let c = 0; c < 4; c++) {
    if (b[r][c] === 0) return true;
    if (c < 3 && b[r][c] === b[r][c + 1]) return true;
    if (r < 3 && b[r][c] === b[r + 1][c]) return true;
  }
  return false;
}


function undo(g: Game): boolean {
  const last = g.history.pop();
  if (!last) return false;
  g.board = last;
  g.gameOver = false;
  return true;
}

Agent 启动 + Artifact 生命周期

const games = new Map<string, { game: Game; artifactId: string; conversationId: string; revision: number }>();


async function startGame(conversationId: string, userId: string) {
  const game = newGame();
  const artifactId = ulid();
  games.set(`${conversationId}:${userId}`, { game, artifactId, conversationId, revision: 0 });


  await agent.sendArtifact(conversationId, {
    artifact: {
      artifact_id: artifactId,
      subtype: "app",
      title: "2048",
      payload: render(game),
      capability_flags: { allows_response: true },
    },
  });
}


function render(g: Game) {
  return {
    ui: "2048",
    board: g.board,
    score: g.score,
    best: g.bestScore,
    moves: g.movesCount,
    game_over: g.gameOver,
    won: g.won,
    can_undo: g.history.length > 0,
  };
}

处理用户操作

agent.addEventHandler(async (event) => {
  if (event.type !== "artifact_response") return;


  const game = findGameByArtifactId(event.payload.ref_artifact);
  if (!game) return;


  const action = event.payload.action;
  let mutated = false;


  switch (action) {
    case "move": {
      const dir = event.payload.payload?.direction;
      if (!["up", "down", "left", "right"].includes(dir)) return;
      mutated = move(game.game, dir);
      break;
    }
    case "undo":
      mutated = undo(game.game);
      break;
    case "restart": {
      Object.assign(game.game, newGame());
      mutated = true;
      break;
    }
    default:
      return;
  }


  if (!mutated) return;
  game.revision += 1;
  await agent.updateArtifact(game.conversationId, {
    ref_artifact: game.artifactId,
    based_on_revision: game.revision - 1,
    artifact: { payload: render(game.game) },
  });
});

客户端 UI 约定

payload.ui = "2048" 客户端按以下结构渲染（V1 内置 Game2048 组件）：

┌──────────────────────────────────┐
│ 2048           分数 1248  最高 4096 │
├──┬──┬──┬──┐                      │
│  │ 2│  │  │   [ 撤销 ]             │
├──┼──┼──┼──┤                      │
│ 2│ 4│  │  │   [ 重开 ]             │
├──┼──┼──┼──┤                      │
│ 4│ 8│16│  │                      │
├──┼──┼──┼──┤   ⬆ ⬇ ⬅ ➡           │
│ 8│16│32│64│   滑动或点方向键        │
└──┴──┴──┴──┘                      │
└──────────────────────────────────┘

客户端：

  • 滑动手势 / 方向键触发 send artifact_response { action: "move", payload: { direction: "up" } }
  • 撤销按钮：{ action: "undo" }
  • 重开按钮：{ action: "restart" }

游戏结束时叠加 “Game Over” + 重开按钮。

触发”开始游戏”

agent.addMessageHandler(async (msg) => {
  if (msg.payload?.type !== "text") return;
  const text = msg.payload.text.trim().toLowerCase();
  if (text === "/play 2048" || text === "玩 2048") {
    await startGame(msg.conversation_id, msg.sender_id);
  }
});

多用户、多游戏并发

每个 (conversation_id, user_id) 一个独立游戏 instance（同一群里 不同用户各玩各的；同一私聊里同一时刻一个游戏）。

如果想让”同一群里多人合作 / 对战玩同一游戏”，把 key 改成 (conversation_id, "shared") 即可——所有用户操作合并到同一棋盘。

排行榜（持久化）

把 best score 写到外部 DB：

import { Pool } from "pg";
const pool = new Pool({ connectionString: process.env.DATABASE_URL });


async function updateLeaderboard(userId: string, score: number) {
  await pool.query(`
    INSERT INTO leaderboard_2048 (user_id, best_score, updated_at)
    VALUES ($1, $2, NOW())
    ON CONFLICT (user_id) DO UPDATE
      SET best_score = GREATEST(leaderboard_2048.best_score, EXCLUDED.best_score),
          updated_at = NOW();
  `, [userId, score]);
}


// 在 game over 时调
if (game.gameOver) {
  await updateLeaderboard(userId, game.score);
}

提供 /leaderboard 2048 命令返回排行榜：

async function showLeaderboard(conversationId: string) {
  const r = await pool.query(`
    SELECT user_id, best_score FROM leaderboard_2048
    ORDER BY best_score DESC LIMIT 10
  `);
  await agent.sendArtifact(conversationId, {
    artifact: {
      subtype: "info",
      title: "2048 排行榜",
      payload: {
        body: r.rows.map((row, i) => `${i + 1}. <U:${row.user_id}>  ${row.best_score}`).join("\n"),
      },
    },
  });
}

性能与配额

项数字
单局平均 update 次数200-500（典型一局走完）
单 update 平均字节~500B（4×4 棋盘 + 元数据）
单局总数据量~150 KB
100 update 上限接近时 SDK warn；如要继续，应 endGame + startGame 新 artifact

100 次 update 是 artifact lifecycle 上限。一局完整 2048 ~300 步会超。 实战做法：每 80 步主动结束当前 artifact，再开一个新的（保留 game 状态在 Agent 端，仅 artifact ID 变更）。
