Artifact 入门

Artifact 是 Agent 推给客户端的结构化数据块。客户端用对应的 renderer 把它 渲染成可交互的卡片：表单、进度条、审批、卡片、媒体。本页讲 Artifact 入门： subtype 列表、payload 结构、最简示例。双向交互（artifact_update + 用户回流）见 Artifact 高级。

subtype 列表

subtype客户端 renderer典型用途
infoInfoCard信息提示卡
replyReplyCard结构化回复
appAppRenderer（按 payload.ui 路由）小程序 / 小游戏 / 自定义 UI
formFormCard收集用户输入
responseResponseCard用户对 form 的反馈
tool_call（内部）触发 tool 调用 UI详见 Tool Call
tool_response（内部）tool 执行结果详见 Tool Call
approvalApprovalCard危险操作确认
progressProgressCard长任务进度
mediaMediaCard图 / 视频 / 音频聚合展示

最简示例：信息卡

await agent.sendArtifact(conversationId, {
  artifact: {
    subtype: "info",
    title: "部署成功",
    payload: {
      body: "你的 Cloudflare Worker 已部署到 us-east-1",
      icon: "✅",
      actions: [
        { id: "open", label: "查看 logs", url: "https://dash.cloudflare.com/..." },
      ],
    },
  },
});

进度卡

const artifactId = ulid();


await agent.sendArtifact(conversationId, {
  artifact: {
    artifact_id: artifactId,
    subtype: "progress",
    title: "导出 Q1 数据",
    payload: { percent: 0, status: "starting", eta_s: 120 },
  },
});


// 长任务更新进度
for (let pct = 10; pct <= 100; pct += 10) {
  await new Promise((r) => setTimeout(r, 5000));
  await agent.updateArtifact(conversationId, {
    ref_artifact: artifactId,
    based_on_revision: (pct / 10) - 1,
    artifact: {
      payload: {
        percent: pct,
        status: pct < 100 ? "running" : "done",
        eta_s: Math.round((100 - pct) * 1.2),
      },
    },
  });
}

详见 Artifact 高级 — artifact_update 与 revision。

表单卡

await agent.sendArtifact(conversationId, {
  artifact: {
    artifact_id: ulid(),
    subtype: "form",
    title: "新建项目",
    payload: {
      fields: [
        { id: "name",        label: "项目名",  type: "text",     required: true },
        { id: "description", label: "描述",    type: "textarea" },
        { id: "private",     label: "私有",    type: "checkbox", default: false },
        {
          id: "visibility",
          label: "可见性",
          type: "radio",
          options: [
            { id: "public",  label: "公开" },
            { id: "private", label: "私有" },
          ],
        },
      ],
      submit_label: "创建",
      cancel_label: "取消",
    },
  },
});


agent.addEventHandler(async (event) => {
  if (event.type !== "artifact_response") return;
  if (event.payload.action !== "submit") return;
  const { name, description, private: isPrivate, visibility } = event.payload.payload;
  await createProject({ name, description, private: isPrivate, visibility });
});

详见 Artifact 高级 — 用户回流处理。

审批卡

await agent.sendArtifact(conversationId, {
  artifact: {
    artifact_id: ulid(),
    subtype: "approval",
    title: "确认部署到生产环境",
    payload: {
      request: {
        environment: "production",
        version: "v2.4.1",
        changes: ["3 commits, 12 files"],
      },
      approve_label: "批准并部署",
      reject_label: "取消",
      timeout_s: 300,
    },
  },
});

approval 是 form 的一种特殊 UI（内置 approve / reject 双按钮 + 倒计时）。 SDK 在 timeout_s 内未收到响应自动 timeout，给你发 artifact_response status=denied reason=timeout。

媒体卡

// 先上传文件得到 attachment_id
const { attachment_id: imageId } = await agent.uploadFile(conversationId, {
  filename: "chart.png",
  mime: "image/png",
  data: chartPng,
  send_as: null,            // 不直接发；只为 artifact 用
});


await agent.sendArtifact(conversationId, {
  artifact: {
    subtype: "media",
    title: "Q1 数据图表",
    payload: {
      items: [
        { type: "image", attachment_id: imageId, caption: "趋势" },
      ],
    },
  },
});

应用卡 (subtype: “app”)

最灵活——任意 React 组件渲染。客户端按 payload.ui 路由 renderer：

await agent.sendArtifact(conversationId, {
  artifact: {
    artifact_id: ulid(),
    subtype: "app",
    title: "今日午餐投票",
    payload: {
      ui: "vote_card",        // 客户端按 ui 选 renderer
      question: "今天午餐吃什么？",
      options: [
        { id: "a", label: "拉面", votes: 0 },
        { id: "b", label: "披萨", votes: 0 },
        { id: "c", label: "沙拉", votes: 0 },
      ],
      total: 0,
    },
    capability_flags: { allows_response: true },
  },
});

客户端内置 renderer 支持 vote_card / tic_tac_toe / 2048 / form / progress， 社区自定义 UI 走 fallback。

详见 小程序与小游戏。

完整 ArtifactSendPayload 字段

interface ArtifactSendPayload {
  artifact: {
    artifact_id?: string;     // 可选；不传 SDK 会生成 ULID（强烈建议自己传以便后续 update）
    subtype:                  // 必填
      | "info" | "reply" | "app" | "form" | "response"
      | "tool_call" | "tool_response" | "approval" | "progress" | "media";
    title?: string;
    payload: object;          // 任意 JSON，由客户端 renderer 解释
    capability_flags?: {
      allows_response?: boolean;
      ttl_s?: number;
    };
    expires_at?: string;      // ISO 8601；过期后客户端自动 disable
  };
}

限制

项上限
单 artifact JSON 大小64 KB（含 wrap）
同对话同时存活的 artifact 数100（超过后老的自动 expire）
artifact 默认存活30 天（除非 expires_at 显式覆盖）
单 artifact update 次数100（防止状态机暴走）

大数据建议放 R2 → artifact payload 里只放引用 url；客户端按需 GET。

客户端 renderer 速读

subtype客户端组件payload 关键字段
infoInfoCardbody, icon, actions[]
formFormCardfields[], submit_label, cancel_label
progressProgressCardpercent, status, eta_s
approvalApprovalCardrequest, approve_label, reject_label, timeout_s
appAppRenderer (按 ui)自定义
mediaMediaCarditems[] (type=image/video/audio + attachment_id)

未匹配的 subtype 走 “Unknown artifact” fallback —— 显示原始 JSON + “Open in browser” 按钮。

接收 artifact_response 概要

agent.addEventHandler(async (event) => {
  if (event.type !== "artifact_response") return;
  const {
    ref_artifact,        // 你之前发的 artifact_id
    action,              // "submit" / "approve" / "reject" / "vote" / 自定义
    payload,             // 用户提交的数据
    sender_id,
  } = event.payload;
  console.log(`user ${sender_id} did ${action} on artifact ${ref_artifact}`);
});

详细处理见 Artifact 高级。

下一步
